Edexcel IGCSE·Mathematics 4MA1
Three Figure Bearings
Key knowledge — Trigonometry
Formulas & equations
sin θ = opposite ÷ hypotenuse (SOHCAHTOA)cos θ = adjacent ÷ hypotenusetan θ = opposite ÷ adjacentSine rule: a/sin A = b/sin B = c/sin CCosine rule: a² = b² + c² − 2bc cos AArea of triangle = ½ ab sin CExact values: sin 30°=½, cos 30°=√3/2, tan 30°=1/√3Exact values: sin 45°=√2/2, cos 45°=√2/2, tan 45°=1Exact values: sin 60°=√3/2, cos 60°=½, tan 60°=√3
Key facts & rules
- SOHCAHTOA only works in right-angled triangles.
- Sine rule: use when you know 2 sides + opposite angle, or 2 angles + any side.
- Cosine rule: use when you know 3 sides (to find an angle), or 2 sides + included angle.
- Bearing: measured clockwise from North, always written as 3 digits (e.g. 045°).
- Angle of elevation: measured upward from horizontal. Angle of depression: measured downward from horizontal.
- For graphs: sin and cos have period 360°, amplitude 1. tan has period 180°.
Three-figure bearings
6 Edexcel IGCSE 4MA1 past paper questions on three figure bearings — Foundation and Higher, with mark schemes.
Question 1 of 6
Show mark scheme
Question 2 of 6
Show mark scheme
Question 3 of 6
Show mark scheme
Question 4 of 6
Show mark scheme
Question 5 of 6
Show mark scheme
Question 6 of 6
Show mark scheme
